Optional Accessories

• Fly jib : 4.1m length
• Fire Extinguisher
• Spark Arrestor
• Canopy
• Air Conditioned Cabin
• Steering Wheel
• Extra hooks
• Man carrying basket
• Forks
• Safe load indicator with hydraulic cut-off

Technical Parameters

Details

Engine

• Simpson S-433 Four Cylinder, Water Cooled Diesel Engine Rated power for crane 49 BHP @ 2200 RPM (Max continuous engine rating 59 @ 2300 RPM) or equivalent Engine

Transmission

• Type Heavy duty transmission developed specially for crane application. Sliding Mesh, spur teeth gearbox. Six forward and two reverse speeds with high and low selector lever.
• Speed Travel Speed 25 Kmph - restricted as per safety norms (without load)
• Clutch Single plate, heavy duty dry friction type clutch plate specially designed for crane application
• Speed Travel Speed 25 Kmph - restricted as per safety norms (without load)
• Clutch Single plate, heavy duty dry friction type clutch plate specially designed for crane application

Steering

• Type Articulated power steering, hydraulically controlled through 2 double acting jacks
• Articulation upto 56˚
• Turning Radius Minimum 5.2 m

Tyres

• Front 11.00x20-16PR (Four Nos.)
• Rear 13.00x24-12PR (Two Nos.)

Boom

• Telescoping Heavy duty, Two part box type hydraulically operated
• Derricking Through double acting jacks.

Hoist Mechanism

• Four falls, hydraulic winch.(Winch capacity 10T) Rope dia 13mm

Capacities

• Fuel Tank 45 Ltrs.
• Hydraulic Tank 90 Ltrs.
• Axle Reduction 2.45 Ltrs.
• Operating Weight(Kg) 8850

Operation weight

• 8450 kg

Safety System

• Overload audio warning system
• Overhoist audio warning system
• Safety brakes on hoist
• Hose protection failure device
• Cylinder guard for protection

Standard Accessories

• All weather cabin
• Front Bumper
• Reflectors
• Lift Cylinder Guard
• Rear View Mirror
• Turn & Reverse lamp
